19 "RACK server cabinet, 32U / 800x800mm, folded, perforated door, black

In 19 "rack cabinets, the following are most often mounted:

• patch panels, i.e. terminations of the LAN network, monitoring, alarms or optical fibers

• power supply systems, power strips, security measures ensuring appropriate power parameters for devices installed in the cabinet rack 19 "

• emergency power supply, UPS

• ventilation systems that provide the devices with appropriate working conditions

• servers and computers

• switches, routers, modems, converters for copper and fiber optic LAN networks

• NVR DVR recorders and others

• Audio-Video devices

The most important features of server cabinets:

• stable and durable structure

• quick installation, standing rack cabinet delivered fully assembled, secured on a pallet

• air vents in the roof and in the floor for natural gravity ventilation and for optional mounting fansWith thermostat or without

• additional perforation on the door

• removable side panels for convenient access to devices

• possibility of installing optional locks in the side panels. (119-000-000-003)

• 4 Rack rails ensuring safe installation of larger devices and the possibility of mounting smaller devices in 2 planes. For example, a power panel behind a switch or a patch panel

• wide range of 19 "rack rail position adjustment

• a wide selection of carefully selected and matched accessories

• possibility of installing the door as right or left

• door opening 220 °

• tempered glass or perforated front glass door with a very good perforation coefficient. There is a possibility of a different configuration

• full, steel or perforated rear door with a very good perforation coefficient. There is a possibility of a different configuration

• holes in the floor and roof for cable entry

• front and rear door lock

• lock of the side panels - optional (119-000-000-003)

• possibility of mounting plinths - optional

Execution:

• Cold-rolled steel sheet

• frame sheet thickness: 1.5 [mm]

• side panel sheet thickness: 1.2 [mm]

• sheet thickness of Rack mounting rails: 2.5 [mm]

• glass thickness: 5 [mm]

Technical parameters:

• load capacity: 800 kg

• front door: perforated with a handle and a lock

• rear door: full steel with a lock

• black colour

• color code: RAL 9004

• basic dimensions 19 ”/ 32U

• height 1605 [mm]

• width 800 [mm]

• depth 800 [mm]

• Weight: 90 kg

• Standards of performance: Compliance with ANSI / EIA RS-310-D, DIN41491 PART1, IEC297-2, DIN41494 PART7, GB / T3047.2-92 standards

• Compatibility with standards: metric ETSI and international 19 "

Contents of the package:

• folded wardrobe packed on a pallet (it is possible to order the wardrobe in parts)

• Rack screws for mounting elements in the cabinet 25 sets

• wheels with blocks - 4 pcs

• durable, adjustable feet - 4 pcs

• Screws for assembly

• height of the packed product: 1750 [mm]

• width of the packed product: 805 [mm]
• depth of the packed product: 805 [mm]

• weight of the packed product: 105 [kg]

Product details

• Mark Netrack

• EAN 5908268779773

• Index 019-320-88-112-Z

Accessories available:

• roof ventilation panel

• roof ventilation panel with thermostat

• plinth
• the shelf
• shelves 19 "
• 19 "digital thermostat
• 19 "2W ventilation panel with thermostat
• 19 "4W ventilation panel with thermostat
• side door lock
• PDU power strips
• Rack screws
• organizers
